OEM ODM 5G Signal Booster For Home

  • 1
  • 2
  • 3

Brand Name : ATNJ

Model Number : AT-Wireless

Certification : CE,ROHS，CCC，TUV,BV， ISO

Place of Origin : China

MOQ : 5Pcs

Price : USD+1350---1500+unit

Payment Terms : T/T, Western Union,Paypal,Alibaba,Bank transfering.

Supply Ability : 1000+unit+per day.

Delivery Time : 3-5 work days

Packaging Details : Standard neutral packing,48x46x18cm(1 kit)

Support Frequency Range : Customized

Device Gain : 80-90dB

Device Output : Uplink: 23±3dBm,Downlink:33±3dBm

Color For Choice : White Cuztomized

AGC Intelligent function : Done,31dB @ 1dB/ Step

ALC Intelligent function : Done

MGC Function : Done

System Delay : ≤ 5μs

RF Connect Type : N/Female

Power Supply : AC 110~220V±20%, 50/60Hz(AC 220V/ DC24V/5A power adapter)

Inter-Modulation Attenuation ACPR : ≤ -40dBc / 30kHz (measured under rated output power)

Device DWeight : 12kg

Contact Now

OEM ODM 5G Signal Booster For Home



Customized High power all network 2G 3G 4G 5G signal booster- 2U chassis - Worldwide



Products Description

OEM ODM 5G Signal Booster For Home

OEM ODM 5G Signal Booster For Home



Signal Booster Frequency Range

CDMA800M Uplink:825~835MHz Downlink:870-880MHz
FDD1800M Uplink:1765~1780MHz Downlink:1860-1875MHz
FDD2100M Uplink:1920~1940MHz Downlink:2110-2130MHz

GSM900M Uplink:904~915MHz Downlink:949-960MHz
FDD1800M Uplink:1735~1765MHz Downlink:1830-1860MHz
FDD2100M Uplink:1940~1980MHz Downlink:2130-2170MHz

GSM900M Uplink:889~904MHz Downlink:934-949MHz
FDD1800M Uplink:1710~1735MHz Downlink:1805-1830MHz
TDD1900M Uplink:1885~1915MHz Downlink:1885-1915MHz
TDD2600M Uplink:2575~2675MHz Downlink:2575-2675MHz


mobile signal booster technical parameter

mobile signal booster

Uplink

Downlink

Max Gain

80

90

Max Gain error

3±

3±

ALC Working Range

≥20

≥20

Passband Ripple

≥6

≥6

Receiver Sensitivity

≥90

...

Max Power

23±3

33±3

Spurious Emission

≤-36dBm/100KHz

≤-36dBm/100KHz

Intermodulation Attenuation

≤-45

≤-45

VSWR

≤25

≤25

System Delay

≤2μs

Further detail pls click here for downloading the products specification:

Signal Booster Parameter index

Working Voltage

DC24V

Working Current

<5A

Power Supply

AC 100~240V 50/60Hz

Working Temperature

-25°c~+55°c

Working Relative Humidity

≤85°c

RF connector

N-K

FDDI connector

FC/APC

Dimensions

480X378X88mm

2U Weight

8.5kg


Signal Booster Products Feature

⭐ Intelligent to guide the installation with LCD .

⭐ Real time display the signal strength .

⭐ Automatic dormancy when no user make the calling .

⭐ Automatic alarm when installation mistake and provide the according solution .

⭐ Automatic adjust the system gain to avoid the repeater self-excitation .

⭐ Initiative reminding when the device was damaged .

⭐ Supports from 0.2 to 20MHz bandwidth adjusted(Customized) .
⭐ Supports 5G bandwidth, 40MHz,50MHz,60MHz,70MHz,80MHz,90MHz,100MHz(Frequency Bandwidth Customized) .

⭐With WIFI Monitor+Control(Customized),NMS(network management system),Function Optional .

⭐ A variety of appearance customization.

OEM ODM 5G Signal Booster For Home


We are manufacturer, and have our own factory.
FAQ:
1. Are you trading company or manufacturer ? Could I use our own logo and label?

We are factory, with trading service. We provide OEM/OEM service.
2. Can I have a sample order? What is your MOQ?
Yes, we welcome sample order to test and check quality. MOQ is 1 for normal products.
3: Is it easy to set up your items?
A: Yes. We have a user manual and support technical support 24/7.
4. What is your warranty time?
We promise 3-year warranty for all products shipped from us. Man-made sabotage and natural factors are not within the scope of warranty.
5. Please feel free to contact us if any other questions.
